Output
|
| Max Configurable Power (Watts) |
480 Watts / 900VA |
| Output Frequency (sync to mains) |
50/60 Hz +/- 1 Hz Sync to mains
|
| Topology |
Line interactive
|
| Waveform type |
Stepped approximation to a sinewave
|
| Transfer Time |
6 ms typical : 10 ms maximum
|
|
Input
|
| Input frequency |
50/60 Hz +/- 5 Hz Auto-sensing
|
| Input voltage range for main operations |
140 - 300 (230 V) ACV
|
| Number of Power Cords |
1 |
| Input Power Factor at Full Load |
0.53
|
|
Batteries & Runtime
|
| Battery type |
Lead-acid battery
|
| Typical recharge time |
8hour |
| Nominal Battery Voltage |
12 V
|
| Expected Battery Life (years) |
2 - 3
|
| Battery Volt-Amp-Hour Capacity |
108
|
|
Communications & Management
|
| Control panel |
LED Status display with on line : on battery
|
| Audible Alarm |
Alarm when on battery : distinctive low battery alarm
|
|
Surge Protection and Filtering
|
| Surge energy rating |
273Joules
|
|
Physical
|
| Maximum H&W&D |
160x120x355 mm |
| Net Weight |
6.0 Kg |
|
Environmental
|
| Operating Temperature |
0 - 40 °C
|
| Operating Relative Humidity |
0 - 95 (Non-condensing) %
|
| Operating Elevation |
0 - 3000meters
|
| Storage Temperature |
-15 - 40 °C
|
| Storage Relative Humidity |
0 - 95 (Non-condensing) %
|
| Storage Elevation |
0 - 3000meters
|
| Audible noise at 1 meter from surface of unit |
40.0dBA
|
| Protection Class |
IP20
|
