Output
|
| Max Configurable Power (Watts) |
360 Watts / 700VA |
| Output Frequency (sync to mains) |
50/60 Hz +/- 1 Hz Sync to mains |
| Topology |
Line interactive |
| Waveform type |
Stepped approximation to a sinewave |
| Transfer Time |
6 ms typical : 10 ms maximum |
|
Input
|
| Input frequency |
50/60 Hz +/- 5 Hz Auto-sensing |
| Input voltage range for main operations |
170 - 280 (230 V) ACV |
| Number of Power Cords |
1 |
| Input Power Factor at Full Load |
0.51 |
|
Batteries & Runtime
|
| Battery type |
Lead-acid battery |
| Typical recharge time |
8hour(s) |
| Nominal Battery Voltage |
12 V |
| Expected Battery Life (years) |
2 - 3 |
| Battery Volt-Amp-Hour Capacity |
84 |
|
Communications & Management
|
| Control panel |
LED Status display with on line : on battery |
| Audible Alarm |
Alarm when on battery : distinctive low battery alarm |
|
Surge Protection and Filtering
|
| Surge energy rating |
273Joules |
|
Physical
|
| Maximum H&W&D |
138x98x310 mm |
| Net Weight |
4.2Kg |
|
Environmental
|
| Operating Temperature |
0 - 40 °C |
| Operating Relative Humidity |
0 - 95 (Non-condensing) % |
| Operating Elevation |
0 - 3000meters |
| Storage Temperature |
-15 - 40 °C |
| Storage Relative Humidity |
0 - 95 (Non-condensing) % |
| Storage Elevation |
0 - 3000meters |
| Audible noise at 1 meter from surface of unit |
40.0dBA |
| Protection Class |
IP20 |
